Modulo®
The low and flat design of the Modulo® allows the load to extend significantly beyond the truck’s confines forwards, backwards, and upwards. The interchangeable middle module ensures quick and easy conversion of the trolley.
When the load is changed, the automation-rich front and rear parts remain unchanged, which significantly reduces the cost of fleet change.
Application
klt container
pallet container
grille container
euro pallet
universal pallet
any container
TYPE B | TYPE E | |
External dimensions (l x w x h) | 2650 x 1160 mm | 2775 x 1160 mm |
Loading space (l x w x h) | 1 x 1200 x 1800 mm 1 x 1200 x 1150 mm | 1 x 1200 x 1800 mm 1 x 1200 x 1000 mm 2 x 800 x 600 mm |
Bearing capacity | 1000 kg | 1000 kg |
Speed | max 6km/h | max 6km/h |
Driving system | 4-wheel steering system | 4-wheel steering system |
Maximal weight of set | 4000 kg | 4000 kg |
Wheel type | poliuretan green, ergonomic, hardness: 75° Shore A | poliuretan green, ergonomic, hardness: 75° Shore A |
All trolleys on offer are manufactured in accordance with DIN EN ISO 3834-2 (quality assurance system in welding), issued by TÜV Rheinland Group and in accordance with PN-EN1757-3.
